Details
Adventure isn’t where you go, it’s how you get there. Search – all day comfort combined with unparalleled performance.
Singletrack, dirt roads, city parks, even the most remote back country trails – are you roaming or racing? The updated Search Carbon is ready for your next gravel adventure with a modernized lightweight carbon frame featuring Norco’s proprietary downtube storage for all your goodies and gear to get you there.
A progressive, modern gravel bike.
Search C GRX features new-school gravel geo fit for a fast, lively, confident ride on any terrain. With a taller headtube, slacker head angle, and longer reach, it’s more stable on rough terrain and ready to tackle steeper grades with ease.
The updated, longer fork adds stability and the new geometry is compatible with suspension forks if you want to add some extra cushion. The frame is UDH compatible and supports fitments for all the latest wide range 1x drivetrain technologies.
Fully guided cable routing and a fully threaded BSA bottom bracket makes maintenance a breeze.
MODERN GRAVEL GEO
Progressive and confidence-inspiring.
Search Carbon features new-school gravel geo fit for a fast, lively, confident ride on any terrain. With a taller headtube, slacker head angle, and longer reach, it’s more stable on rough terrain and ready to tackle steeper grades with ease.
EASY-ACCESS DOWNTUBE STORAGE
Carry everything you could need.
Snacks, tools, layers and survival staples are vital for any adventure. The lightweight carbon frame features downtube storage with two storage bags for all your emergency essentials and a serious stash of gummy bears. The storage handle is CNC-machined aluminum for durability.
CARBON FORK, SUSPENSION READY
A lightweight frame with options.
The updated, longer fork adds stability and is compatible with suspension forks if you want to add some extra cushion. The frame is UDH compatible and supports fitments for all the latest wide range 1x drivetrain technologies.
SIMPLIFIED MAINTENANCE
Updated features for easy wrenching.
Fully guided cable routing and a fully threaded BSA bottom bracket makes maintenance a breeze and cuts down on the amount of time your bike is in the shop. Simply push the cable in one side, and it comes out the other in seconds.
WIDER TIRE CLEARANCE
More traction, when you want it.
With a huge tire clearance, Search Carbon is spec’d with 45c tires and accommodates up to 700 x 50c to fit with loads of mud and gravel on even the gnarliest roads. A custom integrated, low-profile front fender will keep you clean and clear.
FENDER AND BAG MOUNTS
Versatile mount options.
Search Carbon has integrated mounts for full-coverage fenders and adventure-ready accessories. When the world gets wet commuting or training, throw on full-coverage fenders with your fav 45c's. Get ready for epic rides or races with upper and lower top tube mounts to carry snacks, a pump, tools, or anything else you may need right on your frame.
No Other Way Limited Lifetime Warranty
BUILT TO LAST, GUARANTEED.
Search Carbon’s durable frame design, hardware, and component decisions have been made specifically to keep you rolling for longer. Accidents can happen, and when they do, our No Other Way Limited Lifetime Guarantee is our promise to get you back out there as soon as possible.
Frame Size | 5 | 4 | 3 | 2 | 1 |
---|---|---|---|---|---|
Wheel Size | 700c | 700c | 700c | 700c | 700c |
Reach (mm) | 445 | 430 | 415 | 400 | 385 |
Stack (mm) | 634 | 611 | 587 | 564 | 554 |
Head Tube Angle | 69.5° | 69.5° | 69.5° | 69.5° | 69.5° |
Fork Offset (mm) | 51 | 51 | 51 | 51 | 51 |
Seat Tube Length (mm) | 580 | 545 | 510 | 475 | 440 |
Effective Seat Tube Angle | 73.5° | 73.75° | 74° | 74.25° | 74.5° |
Rear Centre Length (mm) | 430 | 430 | 427.5 | 425 | 425 |
Bottom Bracket Drop (mm) | 75 | 75 | 75 | 75 | 75 |
Bottom Bracket Height (mm) | 285 | 285 | 285 | 285 | 285 |
Horizontal Top Tube (mm) | 633 | 608 | 583 | 559 | 539 |
Wheelbase (mm) | 1132 | 1108 | 1082 | 1056 | 1037 |
Standover (mm) | 824 | 791 | 758 | 725 | 691 |
Head Tube Length (mm) | 185 | 160 | 135 | 110 | 100 |
Trail (mm) | 80 | 80 | 80 | 80 | 80 |
Maximum Post Insertion (mm) | 290 | 290 | 290 | 240 | 210 |
Stem Length (mm) | 70 | 70 | 70 | 70 | 70 |
Crank Length (mm) | 172.5 | 172.5 | 170 | 170 | 165 |
Frame Size | Rider Height (cm) | Rider Height (in) |
---|---|---|
1 | 150 - 165 | 5'0" - 5'5" |
2 | 162 - 172 | 5'4" - 5'8" |
3 | 170 - 180 | 5'7" - 5'11" |
4 | 180 - 190 | 5'10" - 6'2" |
5 | 185 - 200 | 6'1" - 6'6" |
Specs
Frame | Search Carbon w/ DT Storage, UDH Compatible |
---|---|
Fork | Search Carbon, 51mm Offset, 12x100mm TA |
Rims | Alloy Tubeless i25 TCS 2.0 |
Hubs |
Front: Shimano HB-TC500, 12x100mm, 28H Rear: Shimano FH-TC500, 12x142mm, HG, 28H |
Spokes | Double Butted, Black Alloy |
Tires | Schwalbe G-One, 700x45c All Round Perf Race Guard |
Bottom Bracket | Shimano Threaded, HOLLOWTECH II ,68/70 mm |
Crankset | Shimano GRX FC-RX610 12spd, BSA 24mm , S1/2=165; S3/4=170; S5=172.5, 40T |
Shifters | Shimano GRX ST610, 12sp |
Rear Derailleur | Shimano GRX RD-RX822, 12sp |
Cassette/Freewheel | Shimano CS-M7100, 10-45T, 12sp |
Chain | KMC X12, 12sp |
Brakes | Shimano GRX BR-RX400 |
Rotors | Shimano SM-RT64, 160mm, C-lock |
Brake Levers | Shimano GRX ST610 |
Handlebars | Norco Super Flare Aluminum Compact, 40cm (S1,S2) - 42cm (S3) - 44cm (S4) - 46cm (S5), 16 Degree |
Tape/Grips | Griptacular Shockproof Tape 3mm |
Stem | Norco SL Alu, 70mm Length, 31.8mm Clamp |
Headset | FSA Integrated Sealed Bearings No. 42 ; Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 ) |
Seatpost | Norco Alu, 27.2mm ID, 350mm Length |
Saddle | Selle Royale SRX Gravel, 148mm Width |
Pedals | Sold Separately |
Accessories & Extras | Norco Storage Bag - Ocean-X Water Resistant |
* Subject to change without notice.
Videos
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Agave / SZ2 / 700c | 058817724350 | 0400515855 | SEA22908219N |
Agave / SZ3 / 700c | 058817724367 | 0400515856 | SEA2231964N |
